Mechanical

Dimensions

• Ø 147 x 49 mm (Ø 5.8 x 1.9 in.)

Weight

• Without Mount: 655 g (1.4 lb)
• With outdoor accessory: 685 g (1.5 lb)

Enclosure Materials

• Aluminium alloy, polycarbonate, hard-coated dome

Mounting Materials

• Polycarbonate, stainless steel

Weatherproofing

• IPX4

Resistance

• IK08

Optics

Sensor

• 5MP CMOS Sensor

Lens

• Fisheye Lens

View Angle

• 360°

Night Mode

• Built-in IR LED illumination and IR cut filter

Video

Resolution

• 4MP 1920 x 1920 (1:1)

Max. Frame Rate

• 30 FPS

Image Settings

• Colour, brightness, sharpness, contrast, white balance, exposure control, 2DNR, 3DNR, masking, text overlay

System

Processor

• Quad-core Arm Cortex-A53 based chip

Networking Interface

• GbE RJ45 port

Power Method

• PoE

Power Supply

• 48V DC, 0.18A PoE

Max. Power Consumption

• 8.64W

Supported Voltage Range

• 37—57V DC

LED

• R/G/B/W

Button

• Factory Reset

Mounting

• Surface mount

Ambient operating temperature

• -20 to 40° C (-4 to 104° F)

Ambient operating humidity

• 10 to 90% noncondensing

Certifications

• FCC, IC, CE

Audio

Microphone

• Yes (can be disabled)

Speaker

• Yes

Software

Controller Software

• UniFi Protect: Version 1.10.0 and later

Mobile Apps

• UniFi Protect iOS and Android

Standard Warranty: 1-Years
