Ubiquiti U6-Enterprise UniFi Tri-Band WiFi 6E Access Point (AX)
Ubiquiti U6-Enterprise UniFi Tri-Band WiFi 6E Access Point is a next-generation, enterprise-grade access point designed to take advantage of WiFi 6E speeds. Ideal for demanding, high-density networks.
IMPORTANT: The Ubiquiti U6-Enterprise UniFi access point is not supplied with a PSU or PoE injector
£259.24 inc.VAT / £216.03 exc.VAT
Ubiquiti U6-Enterprise UniFi Tri-Band WiFi 6E Access Point (10.1Gbps AX)
Ubiquiti U6-Enterprise UniFi Tri-Band WiFi 6E Access Point (AX)
Ubiquiti U6-Enterprise UniFi Tri-Band WiFi 6E Access Point (AX) is a next-generation, enterprise-grade access point designed to take advantage of WiFi 6E speeds. Ideal for demanding, high-density networks.
the U6-Enterprise can support up to 600+ clients over its 2.4GHz, 5GHz, and 6GHz channels. Each of the U6-Enterprise’s three bands also utilizes OFDMA technology, which tactically distributes high volumes of data to ensure that your clients maintain a reliably fast, quality connection.
Key Features
- Supports up to 600+ clients.
- 10.2 Gbps aggregate, over-the-air radio rate.
- 6 GHz band (4×4 MU-MIMO and OFDMA) with a 4.8 Gbps radio rate.
- 5 GHz band (4×4 MU-MIMO and OFDMA) with a 4.8 Gbps radio rate.
- 2.4 GHz band (2×2 MU-MIMO and OFDMA) with a 573.5 Mbps radio rate.
- One (1) 2.5GbE RJ45 port (optimised for use with USW Enterprise series supporting 2.5GbE PoE switching).
- Includes mounting plate, backing plate, and screw kit for quick and easy installation.
- Powered with 802.3at PoE+ (PoE injector sold separately).
Specifications
Mechanical
Dimensions
- Ø 220 x 48.1 mm (Ø 8.66 x 1.89 in.)
Weight
- Without mount: 960 g (2.1 lb.)
- With mount: 1090 g (2.4 lb.)
Enclosure materials
- Top housing: Plastic
- Bottom housing: aluminium
Mount material
- SGCC steel
Hardware
Management interface
- Ethernet
- Bluetooth
Networking interface
- 1 x 2.5GbE RJ45 port
Button
- Reboot and factory reset
LED
- White/blue
Power method
- PoE+
Power supply
- UniFi PoE switch (sold separately)
- 48V, 0.5A PoE adapter (sold separately)
Supported voltage range
- 44 to 57VDC
Max. power consumption
- 22 W
Max. TX power
- 2.4 GHz
- 22 dBm
- 5-7 GHz
- 26 dBm
MIMO
- 2.4 GHz
- 2 x 2 (UL MU-MIMO)
- 5 GHz
- 4 x 4 (DL/UL MU-MIMO)
- 6 GHz
- 4 x 4 (DL/UL MU-MIMO)
Throughput speeds
- 2.4 GHz
- 573.5 Mbps
- 5 GHz
- 4.8 Gbps
- 6 GHz
- 4.8 Gbps
Antenna gain
- 2.4 GHz
- 3.2 dBi
- 5 GHz
- 5.3 dBi
- 6 GHz
- 6 dBi
Mounting
- Wall/ceiling (kits included)
Operating temperature
- -30°C to 60°C (-22°F to 140°F)
Operating humidity
- 5% – 95% noncondensing
Certifications
- CE, FCC, IC
Software
WiFi standards
- 802.11a/b/g
- WiFi 4/WiFi 5/WiFi 6/WiFi 6E
Wireless security
- WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3)
BSSID
- 8 per radio
VLAN
- 802.1Q
Advanced QoS
- Per-user rate limiting
Guest traffic isolation
- Supported
Concurrent clients
- 600+
Zero wait DFS
- Yes
Supported Data Rates (Mbps)802.11a
- 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b
- 1, 2, 5.5, 11 Mbps
802.11g
- 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n (WiFi 4)
- 6.5 Mbps to 600 Mbps (MCS0 – MCS31, HT 20/40)
802.11ac (WiFi 5)
- 6.5 Mbps to 1.7 Gbps (MCS0 – MCS9 NSS1/2/3/4, VHT 20/40/80/160)
802.11ax (WiFi 6/6E)
- 7.3 Mbps to 2.4 Gbps (MCS0 – MCS11 NSS1/2/3/4, HE 20/40/80/160)
Standard Warranty: 1-Years
| Weight | 1.09 kg |
|---|---|
| Dimensions | 22 × 4.81 cm |
