Processor Specs

• 880 MHz MIPS 1004 KEc

Memory Information

• 256 MB

Management Interface

• Ethernet In-Band

Networking Interface

• 1 x 10/100/1000 Mbps Ethernet RJ45

Buttons

• Factory Reset

LEDs

• White/Blue

Power Method

• 802.3af PoE, Passive PoE (48V)

Power Supply

• 802.3af PoE; 48V, 0.32A PoE Adapter (Not Included)

Supported Voltage Range

• 44 to 57VDC

Max. Power Consumption

• 12W

Max. TX Power

• 2.4GHz
  • 23 dBm
• 5GHz
  • 23 dBm

MIMO

• 2.4GHz
  • 2 x 2
• 5GHz
  • 2 x 2

Throughput Speeds

• 2.4GHz
  • 300 Mbps
• 5GHz
  • 1201 Mbps

Antenna Gain

• 2.4GHz
  • 2.8 dBi
• 5GHz
  • 3 dBi

Operating Temperature

• -30 to 60° C (-22 to 140° F)

Operating Humidity

• 5 – 95% Noncondensing

Certifications

• CE, FCC, IC

SOFTWARE

Wi-Fi Standards

• 802.11a/b/g
• Wi-Fi 4/Wi-Fi 5/Wi-Fi 6

Wireless Security

• WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3)
  • Note: Supported With Upcoming Controller Versions

BSSID

• 8 per Radio

VLAN

• 802.1Q

Advanced QoS

• Per-User Rate Limiting

Guest Traffic Isolation

• Supported

Concurrent Clients

• 300+

SUPPORTED DATA RATES (MBPS)

802.11a

• 6, 9, 12, 18, 24, 36, 48, 54 Mbps

802.11n (Wi-Fi 4)

• 6.5 Mbps to 300 Mbps (MCS0 – MCS15, HT 20/40)

802.11b

• 1, 2, 5.5, 11 Mbps

802.11g

• 6, 9, 12, 18, 24, 36, 48, 54 Mbps

802.11ac (Wi-Fi 5)

• 6.5 Mbps to 866.7 Mbps (MCS0 – MCS9 NSS1/2, VHT 20/40/80)

802.11ax (Wi-Fi 6)

• 6.3 Mbps to 1.2 Gbps (MCS0 – MCS11 NSS1/2, HE 20/40/80)

MECHANICAL

Dimensions

• Ø160 x 32.65 mm (Ø6.3 x 1.3″)

Weight

• Without Mount: 300 g (10.6 oz)
• With Mount: 315 g (11.1 oz)

Enclosure Characteristics

• Polycarbonate 110 and ADC12 Die Casting

Mounting Characteristics

• Polycarbonate, SGCC Steel

Package Contents

• 1 x Ubiquiti U6-Lite
• 1 x Ceiling/Wall Mounting Kit
• 1 x Screw Kit
• 1 x Release Tool

Standard Warranty: 1-Years
