Mechanical

Dimensions

• 81.6 x 50 x 47.2 mm (3.21 x 1.97 x 1.86 in.)

Weight

• Without mount: 125 g (4.41 oz.)
• With mount: 163 g (5.75 oz.)

Enclosure material

• Polycarbonate

Mount material

• Polycarbonate

Weatherproofing

• IPX5

Resistance

• IK04

Optics

Sensor

• 5 MP CMOS sensor

Lens

• Fixed focal length EFL 2.8 mm, f/1.6

View angle

• H: 102.4°; V: 54.9°; D: 120.6°

Night mode

• Built-in IR LED illumination and IR cut filter

Video

Compression

• H.264/MJPEG

Resolution

• 2688 x 1512 (16:9)

Maximum frame rate

• 30 FPS

Image settings

• Colour, brightness, sharpness, contrast, white balance, exposure control, 2DNR, 3DNR, NR by motion, masking, text overlay

System

Processor

• Dual core Arm Cortex-A7 based chip

Memory

• 2 GB DDR3

Management interface

• UniFi Protect

Networking interface

• 802.11 a/b/g/n/ac WiFi
• Bluetooth

Flash memory support

• 2 GB

Max. power consumption

• 6W

Power supply

• 5V, 2A USB power adapter (included)

Supported voltage range

• DC 5V, 2A

Link/activity LED

• R/G/B/W

Button

• Factory-reset

Mounting

• Wall mount (included)

Operating temperature

• -20°C to 40°C (-4°F to 104°F)

Operating humidity

• 0% to 90% Noncondensing

Certifications

• FCC, IC, CE

Audio

Microphone

• Yes (can be disabled in UniFi Protect)

Speaker

• Yes

Software

Management application

• UniFi Protect

Mobile apps

• UniFi Protect (iOS/Android)

Standard Warranty: 1-Years
