General Specifications

Dimensions

• Ø 100 x 95 mm (3.9 x 3.7″)

IR Night Vision

• 30 m (98 ft)

Face Recognition

• Yes

Licence Plate Recognition

• Yes

Smart Detection (People, Vehicles, Animals)

• Yes

Resolution

• 4K

Field of View

• H: 109.9°, V: 56.7°, D: 134.1°

Audio

• Microphone

Weatherproofing

• IP66

Tamper Resistance

• IK04

Mounting

• Ceiling, wall (mounts included)
• Arm, pendant, junction box (mounts sold separately)

Performance Specifications

Networking Interface

• 10/100 MbE RJ45 port

Video

• Image Settings: Colour, brightness, sharpness, contrast, white balance, exposure control, 2DNR, 3DNR, NR by motion, masking, text overlay, HDR
• Max. Frame Rate: 30 FPS
• Resolution: 8MP 3864 x 2160 (16:9)

Optics

• Sensor: 1/1.8″ 8MP
• Lens: Fixed focal length
• Night Mode: Built-in IR LED illumination and IR cut filter

Hardware Specifications

Max. Power Consumption

• 12.5W

Supported Voltage Range

• 37–57V DC

Power Method

• PoE

Processor

• Quad-core Arm Cortex-A53 based chip

Weight

• 550 g (1.2 lb)

Enclosure Material

• Aluminium alloy, polycarbonate

Button

• 1 x Factory-reset

Ambient Operating Temperature

• -30 to 50º C (-22 to 122º F)

Ambient Operating Humidity

• 0 to 90% non-condensing

Certifications

• CE, FCC, IC

Cable

• Cable Connector Type: RJ45
• Cable Diameter: 4.5 mm (0.2″)
• Cable Length: 30 cm (1 ft)
• Jacket Material: Thermoplastic elastomer
• Jacket Enclosure Dimensions: Ø 20 x 70.6 mm (0.8 x 2.8″)
• Jacket Enclosure Material: Thermoplastic elastomer, polycarbonate, silicone rubber

Standard Warranty: 1-Years
